Circuit breaker e.industrial.ukm.60S.25, 3p, 25A E.NEXT
Price excl. tax:
€29.63
Price inc. tax:
€35.56
-
Code:i0010026
Power circuit breaker e.industrial.ukm.60S.25, 3p, 25A is designed to protect electrical circuits from prolonged overloads and short-circuit currents, as well as to quickly turn on and off sections of electrical networks with a frequency of 50 Hz and voltage up to 660 V.
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: i0010026
Number of poles: 3
Weight: 0.75 kg
Impulse withstand voltage Uimp: 6 kV
Insulation voltage Ui: 600 V
Application category: A
Terminal tightening torque: 10.5 Nm
Rated operating voltage Ue: AC 600 V
Current type: AC
Rated frequency: 50 Hz
Short-circuit tripping setting Im: 10 In ±20 %
Max. cross-section of connected conductors: 12.5×3 mm²
Protection degree: housing – IP30, terminals – IP00
Compliance with standards: DSTU EN 60947-1, EN 60947-2
Disposal method: handover to a specialized company
Nom. limit breaking capacity Icu: 10 kA
Rated current In: 25 A
Wear resistance mech./el.: < 8500/6000 cycles
Rated operating breaking capacity Ics (AC 400 V): 5 kA
Operating temperature range: -25…+40 °C
Mounting: on mounting panel
Altitude above sea level: ≤2000 m
Characteristics: magnetic-hydraulic distributor
Operating position: vertical or horizontal, with deviation ≤5°
Warranty: 12 months
