Contactor e.industrial.ukc.65.24, 65A, 24V, 3P, 1no+1nc E.NEXT
Price excl. tax:
€61.36
Price inc. tax:
€73.63
-
Code:i.0090036
The e.industrial.ukc.65.24, 65A, 24V, 3P, 1no+1nc contactor is intended for use in stationary installations for remote starting, stopping and reversing by direct connection to the mains of 3-phase short-circuited induction motors, as well as for switching circuits of group lighting and other low inductive loads.
Estimated Shipping
outside Varna starts at
€11.49
to Varna starts at
€11.49
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: i.0090036
Number of poles: 3
Impulse withstand voltage (Uimp): 8 kV
Application category: AC-3
Additional contacts: 1 NO + 1 NC
Max. short-term overload (t ≤ 1 s): 18 In
Altitude above sea level: Up to 2000 m
Insulation voltage (Ui): 690 V
Rated operating voltage (Ue): AC 400/660 V
Current type: AC
Control coil voltage (Uc): 24 V
Rated frequency: 50 Hz
Rated power of controlled motor (AC-3): 30 kW
Pollution degree: 3
Rated operating current (AC-3): 65 A
Protection degree: IP20
Compliance with standards: DSTU EN 60947-1, EN 60947-4-1
Disposal method: Handover to a specialized company
Wear resistance (mechan./el.): ≥ 8,000,000 / 800,000 cycles W/O
Operating temperature range: –25…+40°C
Mounting: On DIN rail 35 mm
Operating position: Any
Warranty: 12 months
