Din-rail button E.PB.DIN.GREEN, GREEN, E.NEXT
Price excl. tax:
€2.22
Price inc. tax:
€2.66
-
Code:i0790002
Din-rail button E.PB.DIN.GREEN, GREEN. Key characteristics: number of lamps: 1 (green); lED current: 0.2 mA; application category: AC-14.
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: i0790002
Number of lamps: 1 (green)
LED current: 0.2 mA
Color: Green
Application category: AC-14
Number of buttons: 1 (green)
Terminal tightening torque: 2 Nm
Altitude above sea level: 2000 m
Insulation voltage Ui: 500 V
Rated operating voltage Ue: AC 230 V
Current type: AC
Rated frequency: 50 Hz
Pollution degree: 2
Max. conductor cross-section: 2.5 mm²
Degree of protection (IP): IP20
Compliance with standards: DSTU EN 60947-5-1
Disposal method: transfer to a specialized company
Conditional thermal current of air: 16 A
Rated current In: 6 A
Mechan./el. wear resistance, cycles: <250,000 / 100,000
Operating temperature range: -10…+40 °C
Mounting: DIN-rail 35 mm
Operating position: any
Warranty: 12 months
