REMEDIAL CURRENT PROTECTION DTZ E.RCCB.PRO.4.63.30, 4P, 63A, 30MA E.NEXT
Price excl. tax:
€24.87
Price inc. tax:
€29.84
-
Code:p003020
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: p003020
Busbar type: without FORK (fork)
Current limitation class: 2
Differential current: 30 mA
Number of poles: 4
Impulse withstand voltage (Uimp): 6 kV
Terminal tightening torque: 3.5 Nm
Altitude above sea level: up to 2000 m
Insulation voltage (Ui): 630 V
Rated operating voltage (Ue): AC 230/400 V
Rated frequency: 50 Hz
Climatic version: UHL4
Max. conductor cross-section: 25 mm²
Protection degree: IP20
Compliance with standard: DSTU EN 61008-1
Limited breaking capacity (Icu): 6 kA
Rated current (In): 63 A
Mechanical/electrical durability: <10,000 / 4,000 cycles
Operating temperature: -25…+40 °C
Switching current: 1000 A
Mounting: DIN rail 35 mm
Type: AC
Mounting position: vertical/horizontal (deviation ≤ 5°)
Weight: ≤320 g
Warranty: 12 months
