POWER CIRCUIT BREAKER E.INDUSTRIAL.UKM.60S.32, 3P, 32A E.NEXT

Technical specifications Article: i0010001 Number of poles: 3 Weight: 0.75 kg Impulse withstand voltage Uimp: 6 kV Insulation voltage Ui: 600 V Application category: A Terminal tightening torque: 10.5 Nm Rated operating voltage Ue: AC 600 V Current type: AC Rated frequency: 50 Hz Short-circuit setting Im: 10 In ±20% Max. connection (busbar): 12.5×3 mm Protection degree: housing IP30; terminal side IP00 Compliance with standards: DSTU EN 60947-1; EN 60947-2 DSTU Disposal method: handover to a specialized company Rated pre-limit breaking capacity Icu: 10 kA Rated current In: 32 A Mechanical/electrical durability: ≤ 8500/6000 cycles Rated operational breaking capacity Ics (AC 400 V): 5 kA Operating temperature: −25…+40 °C Mounting: on a mounting plate Altitude above sea level: no more than 2000 m Characteristics: magnetic-hydraulic disconnector Operating position: vertical/horizontal, deviation up to 5° Warranty: 12 months
