MODULAR CIRCUIT BREAKER E.MCB.PRO.60.1N.С25.THIN, 1P+N, 25A, C, 4.5KA E.NEXT
Price excl. tax:
€2.86
Price inc. tax:
€3.43
-
Code:p055003
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: p055003
Nominal DC voltage, V/pole: 48
Connection of comb type FORK (fork): top and bottom
Current limitation class: 3
Number of poles: 1+N
Time-current characteristic: C
Impulse withstand voltage Uimp: 6 kV
Application category: AC-22B
Terminal tightening torque: 3 N m
Altitude above sea level: up to 2000 m
Insulation voltage Ui: 500 V
Nominal operating voltage Ue: AC 230/400 V
Current type: AC
Nominal frequency: 50 Hz
Climatic version: UHL4
Pollution degree: 3
Max. cross-section of connected conductor, mm²: 25
Protection degree: IP20
Compliance with standards: DSTU IEC 60947-1:2008; DSTU IEC 60898-1:2005
Disposal method: handover to a specialized company
Rated breaking capacity Icn: 4.5 kA
Rated current In: 25 A
Electrical/mechanical durability, B-O cycles: ≥10,000 / ≥20,000
Operating temperature range: −25…+40 °C
Mounting: on DIN-rail 35 mm
Operating position: vertical/horizontal (deviation ≤5°)
Width of 1 pole: 9 mm
Weight: (no more) ~200 g (≈100 g per pole)
Warranty: 12 months
