POWER CIRCUIT BREAKER E.INDUSTRIAL.UKM.630S.500, 3P, 500A E.NEXT
Price excl. tax:
€274.82
Price inc. tax:
€329.78
-
Code:i0010028
Estimated Shipping
outside Varna starts at
€22.50
to Varna starts at
€22.50
to Varna starts at
€14.24
outside Varna starts at
€14.43
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: i0010028
Number of poles: 3
Weight: 10.9 kg
Uimp: 8 kV
Ui: 800 V
Category: A
Tightening torque: 22.5 Nm
Ue: AC 660 V
Current type: AC
Frequency: 50 Hz
Im: 10 In ±20%
Max. cross-section: 40×10 mm²
IP: housing IP30; terminals IP00
Standards: DSTU EN 60947-1; EN 60947-2 DSTU
Icu: 70 kA
In: 500 A
Endurance mech./el.: ≤ 2500/500 cycles
Ics (AC 400 V): 70 kA
Temperature: −25…+40 °C
Busbar: e.industrial.ukm.630S.busbar (i0050005)
Mounting: mounting plate
Height: ≤ 2000 m
Features: thermomagnetic block
Position: vertical/horizontal, up to 5°
Warranty: 12 months
